PDI-5515MG Digital Standard Servo 15.32Kg*cm

This is a digital servo from JX that features a high-quality metal gear. JX’s servomotors are known for their excellent cost-performance ratio. The digital controls of the servo ensure a consistent torque, resulting in faster and more uniform response times.

Servo connection:

• Orange: PWM/Drive signal
• Red: 5VDC
• Brown: GND

Technical details:

• Manufacturer: JX-Servo
• Manufacturer SKU: PDI-5515MG
• Input voltage: 4.8V-6V
• Speed at 4.8V: 0.18s/60°
• Speed at 6V: 0.16s/60°
• Torque at 4.8V: 14.25 kg*cm
• Torque at 6V: 15.32 kg*cm
• Dead band: 2 µs 1520 µs/330hz
• Cable length 260mm
• Max rotation angle: approx. 180°
• Dimensions: 40.5 x 20.2 x 40mm
• Net weight: 16g
• Gross weight: 61g

Package includes:

• 1x PDI-5515MG Digital Standard Servo 15.32Kg*cm
• 1x Screw for Servo Lever

• 4x Mounting screws

• 5x Servo levers

• 2x Rubber dampers

• 4x Metal sleeves for rubber dampers
